Prisms

Strobe Prism-62mm


  • Here's a prism solution that's ideal for night time or any low-light job condition
  • This prism features a strobing LED light
  • The red LED strobes every two seconds
  • All electronics and the battery are securely built in to the canister
  • The battery — a Sanyo CR-1/3N — is the same used in many cameras and will function for approximately 48 hours before needing replacement
  • Features 0.5-second flash
  • The sealed prism canister features an M20 thread, which is standard for screw-in style canisters and fits all holders designed for screw-in style prisms
  • Weighs 0.60 lb (0.26 kg)

Mini Prism System with Center Vial-25mm


  • Here's a versatile prism system in a small package
  • The assembly features a 25 mm copper-coated prism, for fog prevention, a tilting holder, with friction axis, zero or -30 mm offset
  • Powder painted Fluorescent Orange with Fluorescent Yellow targets
  • Includes a 40-min adjustable circular center-mounted vial
  • Assembly can mounted on a Prism pole or tribrach at three heights: 70 mm, 100 mm, 115 mm, or can be hand-held using the plumb bob bracket or with S-hook for quick attachment to plumb bob
  • Also included a point for stake-out work, and a system bag with belt loop
  • Weighs 0.34 lb (0.15 kg)

Mini Prism System with Side Vial-25mm


  • Here's a versatile prism system in a small package
  • The assembly features a 25 mm copper-coated prism, for fog prevention, a tilting holder, with friction axis, zero or -30 mm offset
  • Powder painted Fluorescent Orange with Fluorescent Yellow targets
  • Includes a 40-min adjustable circular side-mounted vial
  • Assembly can mounted on a Prism pole or tribrach at three heights: 70 mm, 100 mm, 115 mm, or can be hand-held using the plumb bob bracket or with S-hook for quick attachment to plumb bob
  • A point for stake-out work (not shown) and a system bag with belt loop are included
  • Weighs 0.34 lb (0.15 kg)

Copper Coated Prism Canister-62mm


  • 62 mm copper-coated prism canister
  • Features an aluminum stud
  • < 5 second accuracy
  • Weighs 0.56 lb (0.25 kg)

Silver Coated Prism Canister-62mm


  • Prism featured in the Walleye Prism System
  • 62 mm Silver-Coated Heavy Duty Prism
  • Featuring 5 sec Accuracy
  • Weighs 0.62 lb (0.28 kg)

Double Right Angle Prism


This prism allows for easy determination of right angle points or perpendicular points between two targets

360° Prism


Prism Constant: 2mm

Prism Accuracy: 5”

Prism Size: 1 Inch (25.4mm)

Mini Stakeout Prism


  • This system tilts and slides up and down pin poles
  • Features a 25 mm, 0 offset silver-coated prism and a high-quality aluminum holder
  • Site cones double as locks
  • The prism has a 40-minute adjustable vial
  • The kit includes four 1-foot (30.5 cm) pole sections each with a 0.50-ft (15.24 cm) mark
  • Prism includes an adapter so it can be used on any pole or tribrach adapter with 5/8 x 11 threads
  • A system bag is also included
  • Weighs 1.40 lb (0.63 kg)

Universal Tilting Prism


  • This -30 mm offset prism holder is constructed from durable aluminum and sealed with a rugged corrosion-proof electrostatic powder paint coating
  • Includes copper-coated (#6411-02-BLK) prism
  • Flourescent Orange
  • Weighs 1.50 lb (0.68 kg)

Measuring Supplies

Short Tapes


  • Various tape lengths in stock
  • Offered in inches, tenths, or metric (some available in inches and tenths)
  • Variations include: Wide tape, Ultra-Bright tape, and more

Long Tapes


  • Long tapes available in 100', 200', and 300'
  • Offered in inches, tenths, or metric (some available in inches and tenths)
  • Variations include fiberglass blade and nylon-coated steel blade

Measuring Wheels


  • A variety of measuring wheels in stock
  • Digital or mechanical counting mechanism

Folding Rules




  • Durable folding rules always in stock
