Spectra Precision Theodolite

---

 Rugged and Dependability makes this David White LT8-300P five-minute instrument the first choice for almost every horizontal and vertical sighting application in construction. The sleek, compact, 26x telescope is engineered to protect against dirt, damage and costly repairs. The horizontal axis features a Trunnion Design for maximum rigidity. Within the protection of the rugged base, the wide-stance ball bearing center guarantees you smooth movement and superior alignment control. The level transit is lined up over a reference point by using an optical plummet, assuring you of precise positioning every time.

Features:

• Powerful 26 power optics
• Objective 32mm
• leveling accuracy of +/- 3/16-inch at 150-foot
• Up to 400-foot range, minimum focus 6 feet
• Field of View - 1'9" @ 100 foot
• Vertical Arc and Horizontal circle with locks and tangents
• 1:100 stadia with glass reticle
• Optical plummet magnification 1.5X
• This unit does have Stadia
• Weight 9.5 lbs instrument only

 Rugged and Dependability makes this David White LT8-300LP five-minute instrument the first choice for almost every horizontal and vertical sighting application in construction. The sleek, compact, 26x telescope is engineered to protect against dirt, damage and costly repairs. The horizontal axis features a Trunnion Design for maximum rigidity. Within the protection of the rugged base, the wide-stance ball bearing center guarantees you smooth movement and superior alignment control. The level transit is lined up over a reference point by using a laser plummet, assuring you of precise positioning every time.

Features:

• Powerful 26 power optics
• Objective 32mm
• leveling accuracy of +/- 3/16-inch at 150-foot
• Up to 400-foot range, minimum focus 6 feet
• Field of View - 1'9" @ 100 foot
• Vertical Arc and Horizontal circle with locks and tangent
• 1:100 stadia with glass reticle
• Laser Plummet makes set-up of center point quick and easy
• This unit does have Stadia
• Weight 9.5 lbs instrument only

 The David White LT8-300LTU is versatile and ideal for use with pipe aligning laser or as a level-transit. The 360 degree telescope design allows direct sight below the instrument for pipe laying applications.

Features:

• Powerful 26X Optics
• Accuracy ±3/16-inch at 150-foot
• Range up-to 400-foot
• Laser plummet for quick and easy set-up
• Horizontal Circle with lock
• Glass reticle with stadia lines for measuring distance (ratio 1:100)
• Plate vial for rough leveling and general plummeting requirements
• Solid 3-piece standards are engineered to protect against dirt, damage and costly repairs
• Wide center ball bearing center assures smooth movement and alignment control
• Top mounted level vial makes setup easy and accurate
• Focus knob is easy to reach no matter what angle you are viewing
• Level transit is lined up over a reference point by using a standard plumb bob
